Spasciani TR82 AC190 compressed air respirator full face kit

Package contents:

• TR 82 – Spasciani full face mask (EN 136:98 CL3, panoramic visor, 5-point harness)
• AC 95 – Spasciani flow regulator (165–230 l/min, alarm <120 l/min, EN 148/1 quick connection)
• TUR 801 – Spasciani breathing hose (corrugated, 50 cm)
• EOD 55 – Spasciani filter silencer (noise reduction and filtration)
• AC190 – Spasciani compressed air filtering unit (coalescent + activated carbon + pressure reducer)
• Compressed air hose 20 m – with safety quick couplings

Options and additional details:

• Supply hoses available in lengths: 5 m, 10 m, 15 m, 20 m, 30 m and 50 m
• Quick coupling options: Eurocoupling (standard) or Spasciani (on request)
• Filtering units available for 1–3 users with different mounting configurations

Spasciani TR82 compressed air respirator kit with full face mask and AC190 filtering unit is an airline respiratory protection system designed for asbestos work and industrial environments requiring continuous breathable air supply and full-face protection.

General information

The system operates as a continuous flow compressed air respirator delivering filtered air directly to the user. The key functional benefit is stable airflow and positive pressure inside the mask, supporting consistent protection throughout the work period.

The package is assembled in-store after ordering, enabling controlled configuration and ensuring component compatibility for the intended application.

Technical specifications

• PRODUCT TYPE: Continuous flow compressed air respirator
• MAIN COMPONENTS: TR 82 full face mask, AC 95 flow regulator, AC190 filtering unit, TUR 801 breathing hose
• PROTECTION CLASS / CERTIFICATIONS: EN 14594:2005 (Respiratory protective devices – compressed air line apparatus), Class 4B :contentReference[oaicite:0]{index=0}
• FACEPIECE: EN 136:98 CL3 (highest class full face mask) :contentReference[oaicite:1]{index=1}
• AIRFLOW: 165–230 l/min (alarm below 120 l/min) :contentReference[oaicite:2]{index=2}
• SUPPLY PRESSURE: 5–6 bar, minimum 250 l/min per user :contentReference[oaicite:3]{index=3}
• AIR QUALITY: EN 12021 (Breathing air standard) :contentReference[oaicite:4]{index=4}
• FILTRATION: Coalescent filter + activated carbon, particle size 0.01 µ, efficiency 99.9999% :contentReference[oaicite:5]{index=5}
• OIL CONTENT: <0.01 mg/m³ :contentReference[oaicite:6]{index=6}
• CONSTRUCTION: Positive pressure system with overflow valve
• NOISE REDUCTION: EOD 55 filter silencer
• WEIGHT: approx. 1.4 kg (excluding hoses) :contentReference[oaicite:7]{index=7}
• MATERIALS: EPDM mask body, polycarbonate visor, polyurethane hose :contentReference[oaicite:8]{index=8}
• HOSES: Antistatic rubber hoses with safety quick connectors
• MANUFACTURER: Spasciani

Benefits and differences compared to similar products

• Continuous airflow with positive pressure improves sealing performance compared to filter-based systems.
• Integrated air filtration reduces dependency on upstream compressed air quality.
• Flow regulator alarm enhances operational safety in case of airflow reduction.
• 5-point harness improves face seal consistency compared to simpler harness systems.

Intended use

The product is suitable for asbestos removal, chemical handling, confined space work and industrial cleaning tasks where exposure is high and continuous protection is required. It is intended for applications where a documented and consistent protection level is necessary.

The product is not suitable without EN 12021 compliant air supply or for environments containing gases such as carbon monoxide not removed by the filtration unit. In practice, the system is selected where protection must remain stable and independent of filter loading.

Asbestos removal 2025: regulatory robustness of respiratory protection

Regulation concerning asbestos removal is tightening, increasing the employer’s responsibility to ensure adequate respiratory protection. Inspections focus on whether protection can be considered unequivocally sufficient in all conditions.

This has led to increased adoption of compressed air systems, as their protection level is consistent and demonstrable without interpretation.

• Clear regulatory robustness without ambiguity
• High and consistent protection level in demanding environments
• User confidence in the protection solution

In practice, this requires evaluating current respiratory protection and transitioning to compressed air solutions before regulatory changes take effect.

Q & A

Is the product covered by warranty?

Warranty terms are specified separately on the product page or in quotation.

Is the product available?

Delivery time is factory order, typically approximately 2–4 weeks. Confirm exact lead time with the seller.

How are technical inquiries handled?

Technical inquiries should be submitted in writing to ensure correct specification of air supply, connections and application requirements.

Delivery information

The package is assembled in-store after ordering. Delivery is based on factory order lead time (approximately 2–4 weeks).

Delivery methods and availability are specified separately on the product page. Exact delivery time is confirmed at order stage.
